25G IPMX Uncompressed Transceiver
The P-AVN-6S is a single-channel uncompressed IPMX and SMPTE ST 2110 transceiver built for environments where broadcast-grade signal integrity and ProAV interoperability must operate on the same network. With native 12G-SDI I/O, PTP-to-Genlock conversion, and both 1GbE and 25GbE connectivity, it provides a direct integration path between traditional baseband infrastructure and open-standard IP distribution. JPEG-XS is also supported for bandwidth-optimized workflows over existing 1GbE infrastructure.
Why choose the P-AVN-6-S?
- IPMX-Based Open Standards
Built on IPMX protocols for future-proof AV-over-IP deployment.
- Uncompressed Video Transport
Single-channel uncompressed IPMX and SMPTE ST 2110 transport up to 4K60 at approximately 18 Gbps, with BT.709 and BT.2020 color gamuts and HDR10/HLG support.
- PTP-to-Genlock Conversion
Synchronizes SDI outputs to IP-based timing with ±12 pixel phase accuracy via a dedicated Genlock BNC. No external timing converters needed in hybrid SDI/IP environments.
- 25GbE with ST 2022-7 Redundancy
Dual SFP28 interfaces support 10GbE and 25GbE with hitless redundancy on independent primary and secondary network paths.
- NMOS Control
IS-04, IS-05, IS-08, and IS-11 support for device discovery, connection management, audio mapping, and stream compatibility in managed IPMX deployments.
- Advanced Audio Integration
Support for Dante, AES67, and Linear PCM ensures professional-grade audio quality.
25G IPMX Uncompressed Transceiver
The P-AVN-6S is a single-channel uncompressed IPMX and SMPTE ST 2110 transceiver built for environments where broadcast-grade signal integrity and ProAV interoperability must operate on the same network. With native 12G-SDI I/O, PTP-to-Genlock conversion, and both 1GbE and 25GbE connectivity, it provides a direct integration path between traditional baseband infrastructure and open-standard IP distribution. JPEG-XS is also supported for bandwidth-optimized workflows over existing 1GbE infrastructure.
Why choose the P-AVN-6-S?
- IPMX-Based Open Standards
Built on IPMX protocols for future-proof AV-over-IP deployment.
- Uncompressed Video Transport
Single-channel uncompressed IPMX and SMPTE ST 2110 transport up to 4K60 at approximately 18 Gbps, with BT.709 and BT.2020 color gamuts and HDR10/HLG support.
- PTP-to-Genlock Conversion
Synchronizes SDI outputs to IP-based timing with ±12 pixel phase accuracy via a dedicated Genlock BNC. No external timing converters needed in hybrid SDI/IP environments.
- 25GbE with ST 2022-7 Redundancy
Dual SFP28 interfaces support 10GbE and 25GbE with hitless redundancy on independent primary and secondary network paths.
- NMOS Control
IS-04, IS-05, IS-08, and IS-11 support for device discovery, connection management, audio mapping, and stream compatibility in managed IPMX deployments.
- Advanced Audio Integration
Support for Dante, AES67, and Linear PCM ensures professional-grade audio quality.
