4x1 Simultaneous BYOM Transceiver with Dante Taska IPE-245UDB-STZ is a 4x1 Simultaneous BYOM Transceiver with Dante. It designed as a high-performance codec solution for modern meeting rooms and educational environments. Based on an advanced processor architecture, it features simultaneous real-time encoding and decoding capabilities powered by NeuroMesh Codec technology, supporting input and output resolutions up to 4K@60Hz. The system features dual HDMI and dual USB-C inputs with automatic and seamless switching, alongside an integrated audio DSP and a 2x2 Dante® network audio module. It converts the decoder video into UVC and Dante® audio into UAC,transmitting them via USB-B or USB-C to achieve full BYOM functionality. Operating via 1G fiber or 1G Ethernet interfaces with low latency down to 16ms (1 frame), the IPE-245UDB-STZ provides complete matrix routing, video wall processing, and multi-view windowing configurations for highly versatile collaborative workspaces.
Simultaneous real-time encoding and decoding by NeuroMesh Codec
Compliant with HDMI 2.0b and HDCP 2.2 specifications, with resolutions up to 4K@60Hz 4:4:4
Supports video and text dual modes, with latency as low as 16 milliseconds
Supports two HDMI inputs, two USB-C inputs, one HDMI loop output, and one decoded HDMI output
Four inputs support both automatic and manual seamless switching modes
Four channels of UVC/UAC, supporting 1080P60 USB2.0/USB3.0 high-quality capture
Enables BYOM by converting the local decoder video stream into standard UVC format and bridges Dante® network audio into UAC format.
When powered by DC, USB-C inputs support 100W (single port) / 60W+60W (dual ports) charging (DC power supply is not included by default)
LPCM 2CH audio of various sampling frequencies is normalized to 48KHz before being sent for encoding processing
Supports audio DSP mixing, equalization, delay, volume, and mute processing
Supports Dante 2x2 network audio
Supports independent 1G network port adaptive transmission of Dante (100M network) audio
Supports RS-232 serial routing pass-through and Guest mode (Command relay mode)
Supports point-to-point extension (factory default); adding a Gigabit switch enables Matrix, Video Wall, and Multi-View functions
Supports seamless switching and simultaneous image output on multiple decoders
RTSP output with audio, RTSP main/sub supports On/Off control
Supports window roaming (up to 36 windows)
Supports LCD video walls and LED large screens with any resolution
Supports importing images for when there is no input signal
Supports scrolling text (marquee)
Supports IPC import
Supports PoE+ and DC power supply
Supports 1U/6U V2 chassis (installed at 2 units per 1U)

4x1 Simultaneous BYOM Transceiver with Dante Taska IPE-245UDB-STZ is a 4x1 Simultaneous BYOM Transceiver with Dante. It designed as a high-performance codec solution for modern meeting rooms and educational environments. Based on an advanced processor architecture, it features simultaneous real-time encoding and decoding capabilities powered by NeuroMesh Codec technology, supporting input and output resolutions up to 4K@60Hz. The system features dual HDMI and dual USB-C inputs with automatic and seamless switching, alongside an integrated audio DSP and a 2x2 Dante® network audio module. It converts the decoder video into UVC and Dante® audio into UAC,transmitting them via USB-B or USB-C to achieve full BYOM functionality. Operating via 1G fiber or 1G Ethernet interfaces with low latency down to 16ms (1 frame), the IPE-245UDB-STZ provides complete matrix routing, video wall processing, and multi-view windowing configurations for highly versatile collaborative workspaces.
Simultaneous real-time encoding and decoding by NeuroMesh Codec
Compliant with HDMI 2.0b and HDCP 2.2 specifications, with resolutions up to 4K@60Hz 4:4:4
Supports video and text dual modes, with latency as low as 16 milliseconds
Supports two HDMI inputs, two USB-C inputs, one HDMI loop output, and one decoded HDMI output
Four inputs support both automatic and manual seamless switching modes
Four channels of UVC/UAC, supporting 1080P60 USB2.0/USB3.0 high-quality capture
Enables BYOM by converting the local decoder video stream into standard UVC format and bridges Dante® network audio into UAC format.
When powered by DC, USB-C inputs support 100W (single port) / 60W+60W (dual ports) charging (DC power supply is not included by default)
LPCM 2CH audio of various sampling frequencies is normalized to 48KHz before being sent for encoding processing
Supports audio DSP mixing, equalization, delay, volume, and mute processing
Supports Dante 2x2 network audio
Supports independent 1G network port adaptive transmission of Dante (100M network) audio
Supports RS-232 serial routing pass-through and Guest mode (Command relay mode)
Supports point-to-point extension (factory default); adding a Gigabit switch enables Matrix, Video Wall, and Multi-View functions
Supports seamless switching and simultaneous image output on multiple decoders
RTSP output with audio, RTSP main/sub supports On/Off control
Supports window roaming (up to 36 windows)
Supports LCD video walls and LED large screens with any resolution
Supports importing images for when there is no input signal
Supports scrolling text (marquee)
Supports IPC import
Supports PoE+ and DC power supply
Supports 1U/6U V2 chassis (installed at 2 units per 1U)
