The HDMI 4K/ST2110 over IP Uncompressed Gateway Converter supports the ST-2110 AV over IP protocol standard for Broadcast applications. The unit allows lower cost HDMI 4K equipment to be utilized in a broadcast environment, while extending end point source and sink devices at up to 1300ft (400m) via duplex multimode OM4 fiber with LC connectors, at up to 4K resolution @ 30Hz uncompressed (4K 4:4:4 8 bit and 4K 4:2:2 10 bit), in a point-to-point configuration. Point-to-multipoint and multipoint-to-multipoint configurations are also supported by connecting several units to a 10G Ethernet network. The device supports ST-2022-7 (Class D) Redundancy for critical fail-safe applications allowing the audio/video signal to run over two independent 10G Ethernet Networks. The unit provides a 1G Ethernet Network port for control via 3rd party management platforms supporting a RestAPI, or NMOS (IS-04 for discovery and IS-05 for connectivity management).
Applications:
Commercial broadcast AV systems News/sports/TV stations Movie networks
The HDMI 4K/ST2110 over IP Uncompressed Gateway Converter supports the ST-2110 AV over IP protocol standard for Broadcast applications. The unit allows lower cost HDMI 4K equipment to be utilized in a broadcast environment, while extending end point source and sink devices at up to 1300ft (400m) via duplex multimode OM4 fiber with LC connectors, at up to 4K resolution @ 30Hz uncompressed (4K 4:4:4 8 bit and 4K 4:2:2 10 bit), in a point-to-point configuration. Point-to-multipoint and multipoint-to-multipoint configurations are also supported by connecting several units to a 10G Ethernet network. The device supports ST-2022-7 (Class D) Redundancy for critical fail-safe applications allowing the audio/video signal to run over two independent 10G Ethernet Networks. The unit provides a 1G Ethernet Network port for control via 3rd party management platforms supporting a RestAPI, or NMOS (IS-04 for discovery and IS-05 for connectivity management).
Applications:
Commercial broadcast AV systems News/sports/TV stations Movie networks
