HT-VERSA-4K-S
HT-VERSA-4K is a complete AV over IP solution, which can extend 4K video with one frame latency, USB 2.0, keyboard, mouse, IR, RS-232, and analog audio over a simple Gigabit Ethernet Network.
Categories
Brand
Formfactor
Unit Type
Display
Video Resolution
Video Port Specifications
Network Ports
Network Specifications
Latency (Best)
Supported Switch Brands
Country of Origin
Overview
HT-VERSA-4K is a complete AV over IP solution, which can extend 4K video with one frame latency, USB 2.0, keyboard, mouse, IR, RS-232, and analog audio over a simple Gigabit Ethernet Network. Remote PC Management
Features
• Extend and switch multiple 4K HDMI video and USB on a simple gigabit LAN • Can be used directly (without LAN) for point-to-point HDMI/DVI video, USB 2.0, Audio, IR, and RS232 extension on Cat6 cable • Low latency video and audio (<30ms) • Video rotation and flipping (horizontal and vertical) • User configurable video-wall processor • Extends signals up to 120m (400ft) • HDMI video loop output on the sender • Extracted HDMI audio in stereo analog format on both sender and receiver • 4 USB ports on the Receiver, 2 for keyboard and mouse plus 2 general purpose USB 2.0 ports • PoE powered • USB Device Class Filtering • CEC, IR, and RS-232 Serial over IP for controlHall Technologies • Automatic KVM switching (when more than one receiver is routed to one source) • Telnet and integrated Web UI control • Front panel character LCD for configuration of IP parameters and status indication • Receivers include small IR remote controller for switching channels • Senders accept max resolution of 4K@30Hz 4:4:4 on its input and loop output • Receivers output a max resolution of 4K@30Hz 4:4:4 • HDCP2.2 and 1.4 compliant
Overview
HT-VERSA-4K is a complete AV over IP solution, which can extend 4K video with one frame latency, USB 2.0, keyboard, mouse, IR, RS-232, and analog audio over a simple Gigabit Ethernet Network. Remote PC Management
Features
• Extend and switch multiple 4K HDMI video and USB on a simple gigabit LAN • Can be used directly (without LAN) for point-to-point HDMI/DVI video, USB 2.0, Audio, IR, and RS232 extension on Cat6 cable • Low latency video and audio (<30ms) • Video rotation and flipping (horizontal and vertical) • User configurable video-wall processor • Extends signals up to 120m (400ft) • HDMI video loop output on the sender • Extracted HDMI audio in stereo analog format on both sender and receiver • 4 USB ports on the Receiver, 2 for keyboard and mouse plus 2 general purpose USB 2.0 ports • PoE powered • USB Device Class Filtering • CEC, IR, and RS-232 Serial over IP for controlHall Technologies • Automatic KVM switching (when more than one receiver is routed to one source) • Telnet and integrated Web UI control • Front panel character LCD for configuration of IP parameters and status indication • Receivers include small IR remote controller for switching channels • Senders accept max resolution of 4K@30Hz 4:4:4 on its input and loop output • Receivers output a max resolution of 4K@30Hz 4:4:4 • HDCP2.2 and 1.4 compliant
